MAZAK Horizontal CNC Lathe – QTE-200MY SG (500U)
AUTO SHOT BLASTING
Automated surface cleaning and preparation
for improved coating adhesion.
Original Area : 560 sq.m.
Additional Area : +360 sq.m.
Total Expanded Area : 920 sq.m.
Model: MP100i
Marking Area: $100 \times 100$ mm
Max. Marking Height: Up to 320 mm
Font Size: $1.0 – 100$ mm
Marking Types: Linear, angles, arcs, serial numbers, dates, codes, and logos
Table Cutting : 2500×6000 mm.
Cutting Carbon steel : 1-20 mm.(O2)
Cutting stainless steel : 1-16 mm.(N2)
Cutting Aluminium : 1-16 mm.(N2)
Model: VCN-700D L
Table Size: $1740 \times 700$ mm ($68.5 \times 27.56$ in)
Max. Table Load: 2,000 kg (4,409 lbs)
Max. Spindle Speed: 8,000 RPM (Standard spec) (or optional high-speed/high-torque variants depending on configuration)
Working Volume : 2.5 meters (8.2 feet)
Arm Configuration : 7-Axis
Contact Measurement (ISO 10360-12) : Volumetric Accuracy ± 0.026$ mm
Non-Contact / Laser Scanning (ISO 10360-8) : Compatible with FAROBlu® Laser Line Probes (xS, xR, xP)
for high-speed, high-resolution point cloud capture
Arm Configuration : 6-Axis (designed specifically for high-accuracy contact/tactile measurement and hard probing)
Working Volumes & Accuracy Options (Per ASME / ISO standards):
1.2m (4 ft) Model:
Volumetric Accuracy : ± 0.023$ mm (± 0.0009$ in)
Single Point Repeatability: 0.016 mm (0.0006 in)
PAINT ROOM EXPANSION
Expanded paint and polishing facilities with a monorail system to enhance production capacity and material handling efficiency.
